Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Arch #13 Showing operation of bending 24" vertical steel in groin with use of truck jack and maul. All sheets were bent cold.
Type
Visual Materials(Opens in new tab)
Date
6/1/1942
Call number
photCL SCE 02 - 24708
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
