Big Creek, Florence Lake Dam

Description: Big Creek, Florence Lake Dam - Record photo of typical vertical crack in 1" buffer gunite at base of river section arches. There are approximately 3 such cracks per arch. This particular crack is on Arch 55.
Type: Visual Materials(Opens in new tab)
Date: 5/6/1943
Call number: photCL SCE 02 - 24874
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
